1
KEY NO. PART NO. DESCRIPTION
1 A123324-1 2-1/2” Rod
2 A123324-2 Barrel Weldment
3 A123324-3 Lock Nut 1-1/2”-12
4 A123324-4 Piston
5 A123324-5 Gland
6 A123324-6 Rod Seal
7 A123324-7 Rod Wiper
8 A123324-8 Wear Ring
9 A123324-9 Piston Seal (2-pc.)
10 A123324-10 O-ring
11 A123324-11 O-ring
AHS-00140 Seal Kit (Items 6-11)
12. A123381 Pin 1-1/2” x 10-3/4”
13. AFP-00001 1/4” x 3” Cotter Pin
