Ashland I-900 Ver 1-2007 - Manual (Page 15)

1
KEY NO. PART NO. DESCRIPTION
1 A90H25 Barrel Assembly
2 A80H22 Clamp ring
3 A80H23 Retainer ring
4 A80H24 O-ring, 4” OD x 1/8”
6 A400H12B Seal 2” ID
7 A80H25 Head gland
8 A80H06 Wiper seal, 2” ID
9 AFB-00009 Bolt, 1/2” NF x 4-1/2”, Gd. 5, w/ nut
10 8602 Cotter pin, 1/4” x 2”
11 A8061 Pin, 1-1/4” x 4-3/4”
12 A90H26 Rod assembly
13 A80H27 Piston
14 A300H05 Backup washer, 4” OD
15 A300H06 O-ring, 4” OD x 3/16”
16 A300H04 Cast iron ring, 4” OD
17 A400H17 Piston nut, 1-1/4” NF
18 A8062 Pin, 1-1/4” x 7”
19 AFN-00011 Nut, 1-2” NC
A80H30 Packing kit containing:
1 - A80H24 2 - A300H05 1 - A400H12
1 - A300H06 1 - A400H12A 1 - A300H04
1 - A80H06
