Ashland I-900 Ver 1-2007 - Manual (Page 12)

1
KEY NO. PART NO. DESCRIPTION
1 A9060 Spindle, Rear with flange base plate, s.n. 17908 above
2 A8020 Grease seal ( CR 35062 )
3 A9061 Bearing cone, inner s.n. 17908 above (Timken 39585)
4 A8022 Bearing cup, inner ( Timken 39520 )
5 A8023 Hub
6 A4519 Wheel bolt, 9/16” NF
7 A8024 Bearing cup, outer ( Timken 3525 )
8 A8025 Bearing cone, outer ( Timken 3585 )
9 A6022A Wheel, 16.1 x 11” DC, front
A6023 Large wheel 24” x 15”, rear
10 A8026 Hub cap
11 AFP-00002 Cotter pin, 3/16” x 1-3/4”
12 AFN-00005 Spindle nut
13 A8027 Spindle washer, special
14 AFB-00001 Bolt, 1” NC x 6-1/2” long
15 AFN-00012 Nut, 1” NC
16 AFW-00001 Flat washer, 1”
