Icon Swivel Hitch
A-
KEY # PART NUMBER QUANTITY REQUIRED DESCRIPTION
1 A125224-01 1 Yoke: A-Frame swivel
3 A125224-03 1 Bracket: 10 Hole
4 A125224-04 1 Pin: Main Vertical
5 A125224-05 1 Spacer: 6”
7 A125224-07 4 Bushing
8 A125224-08 2 Seal: O-ring
9 A125224-09 2 Seal: O-ring
10 A125224-10 2 O-ring
13 A125224-13 1 Spacer: 6”
14 A125224-14 2 Washer: 2 1/2”
15 A125224-15 1 Nut: Slotted 2-1/2” NC
16 A125224-16 1 Sleeve: 2” Rubber
17 A125224-17 1 Cap: For Vertical Pin
18 A125224-18 1 Pin: Cotter 3/8 x 5”
19 14505 4 Grease Fitting Straight
20 A125057-02A 2 Bushing
21 AHF-00027 1 Zerk 45°
