Transport locks, Ashland scrapers – Ashland I-200TS4 ver 0612 User Manual
Page 5
Ph: (715) 682-4622 Fx: (715) 682-9717
Ashland Scrapers
www.AshlandInd.com
3
Transport Locks
IMPORTANT: Please locate red transport links and remove prior to scraper operation.
Retract lift cylinder circuit, remove safety snap pin, remove link, and place into storage
position as show in Figure 2 below. Reinstall safety snap pins.
KEY
PART
DESCRIPTION
2
A123309-83
Transport Lock (TS, 15-20yd
3
)
Carry
Position
