Torque Specifications
Lubrication
Grease all zerks after every 8 hours of operation. Use high quality, general-purpose
grease. Grease until grease flows from around the pin.
BOLT DIAMETER TORQUE (ft-lbs)
1/4” 12
5/16” 25
3/8” 45
7/16” 70
1/2” 110
9/16” 150
5/8” 220
3/4” 380
7/8” 600
1” 900
1-1/8” 1280
Lug Nuts 85-100/9yd 450/11-13yd 750/15yd & Up
Lubrication Points
• Hitch - horizontal and vertical pins
• Lift Cylinders - rod end and trunion, left and right sides
• Front Arm Pivot Joint - left and right sides
• Apron Cylinders - rod clevis pin, left and right sides
• Apron Pivot Pin - left and right sides
• Hold-down Rollers - left and right sides
• Floor Rollers - left and right sides
• Tapered Rollers - left and right sides
