Settings for four Pilot servers are provided. Default settings for each are “0.0.0.0” and
port “8800”. An N-111 will not attempt to connect to a Pilot server whose address is still
“0.0.0.0”, but will begin attempting to connect as soon as a valid address is entered and
saved.
For each of the four target servers, an indication of “CONNECTED” or “NOT
CONNECTED” is provided to show if the N-111 has successfully connected to that
server.
In order to send email notifications the N-111 needs to connect to an SMTP mail server.
The server may be an IP Address or mail server URL. In the case of a URL, at least one
DNS server must be specified on the IP Ethernet set up page.
A ‘Mail status’ indication is provided to indicate the status of any attempt to send an
Email message.
Setting Default Value Range
To address 80 characters
SMTP Mail server 64 characters
Login name 64 characters
Password 16 characters
Retries 3 tries every 15 minutes 0-999, 0-999
