Power Mac G4 Optical Drive -

4

3.

Carefully detach the ribbon cable tape from the top of the carrier.

(Figure 4)

4.

Disconnect the following cables from the back of the CD/DVD/Zip drives:

• ribbon cable from the CD/DVD and Zip drives

• power cable (P6) from the CD/DVD drive

• power cable (P7) from the Zip drive

Figure 4

5.

Remove the carrier and drives from the computer.

6.

Remove the four CD/DVD drive carrier mounting screws.

(Figure 5)

7.

Slide the drive out of the carrier.

Figure 5
