5

P

ARTS

M

ANUAL

Ag-Bag International, Ltd.

G7000 June 2004

Appendix A

Towing System - Parts List

Item#

Part#

Description

Qty.

Remarks

1

1120011

Bar, Wheel Turn

1

2

1010035

Lock, Manual Steering Wheel

2

3

Ref.

Nut, Hex

2

1/4-20

4

Ref.

Washer, Flat

2

1/4

5

Ref.

Coupler, Hydraulic

4

6

1212008

Manifold, Cylinder Check Valve

7

Ref.

Capscrew, Hex

2

1/4-20nc x 2-1/2

8

1541795

Valve, PO Check

1

9

1501094

Cap, Plastic Female Pioneer

2

10

1540369

Cylinder, Hydraulic

2

3 x 18

11

1540115

Coupler, quick Female

2

1/2 NPTF

12

1120046

Pin, Pintle Hitch

1

1-1/4 x 5-1/4

13

1550170

Pin, Hitch

2

1 x 8

14

Ref.

Brace, Pintle Hitch

1

15

Ref.

Pin, Hair

5

16

Ref.

Hitch Pintle

1

17

Ref.

Jack Base, Two End

1

18

1541342

Cylinder, Hydraulic

1

3 x 18

19

Ref.

Pin, Clevis

2

20

1100081

Fitting, Assembly

2

C5405 x 8 x 8 - 7238 x 6.055

21

Ref.

Hose Assembly, Jack Long

1

22

Ref.

Hose Assembly, Jack Short

1
