37

P

ARTS

M

ANUAL

Ag-Bag International, Ltd.

G7000 June 2004

Appendix A

Bag Pan System - Parts List

Item#

Part#

Description

Qty.

Remarks

1

Ref.

Capscrew, Hex

3

3/4-10nc x 3

2

Ref.

Nut, Hex

3

3/4-10nc lock

3

Ref.

Lever, Crank, Bag Pan Lift

2

4

Ref.

Nut, Hex

2

1/2-13nc lock

5

Ref.

Capscrew, Hex

4

3/8-16nc x 1

6

Ref.

Washer, Flat

4

3/8

7

Ref.

Spacer, Bag Pan Crank

4

8

1500577

Turnbuckle, Eye to Eye

2

5/16 x 4-1/2

9

1501509

Link, Quick

1

1/4

10

1520702

Chain

2

7-links

11

Ref.

Capscrew, Hex

2

1/2-13nc x 3-1/2

12

1060029

Lever, Bag Pan Lift

2

13

Ref.

Washer, Split Lock

4

14

Ref.

Nut, Hex

4

3/8nc lock

15

7006007

Bag Pan

1
