Ag-Bag G7000 User Manual
Page 41
41
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
G7000 June 2004
Appendix A
Feet Table Drive and Idle End - Part List
42
Ref.
Washer
8
1/2 flat
43
Ref.
Cap Screw, Hex Head
4
1/2-13 x 1-1/2
44
Ref.
Washer
4
1/2 split lock
45
Ref.
Cap Screw, soc hd
4
1/2-13nc x 1-3/4
46
1540916
Motor, Hydraulic
1
47
Ref.
Nut, Hex
1
3/4-10nc
48
1550404
Cap Screw
1
3/4-10nc x 3-1/2 square
49
1520340
Sprocket
1
50
1510031
Bearing
1
51
1080082
Key
1
1/2 sq x 2
52
1520341
Chain, Roller
5.5
feet
1520342
Link, Roller Chain
1
100h connecting
1520084
Link, Roller Chain
1
100 offset
53
1520104
Sprocket
1
54
Ref.
Set Screw
1
5/8 x 5/8
55
Ref.
Cap Screw, Hex Head
8
1/2-13nc x 1-1/4 G5
56
1080050
Bushing, Feed Table Wing
4
57
1080155
Roller, Feed Table Drive
1
58
1080116
Wing, Feed Table Standard
1
right
1080203
Wing, Feed Table Extended
1
right
59
Ref.
Stud
4
9/16-12nc x 1-3/4
60
Ref.
Cap Screw
1
1/2-13nc x 2-1/2 square
61
Ref.
Washer
8
5/8 flat
63
Ref.
Nut, Hex
24
1/2-13nc lock
64
1080182
Bearing, Type E
1
65
1080064
Mount, Feed Table Bearing
1
66
Ref.
Skirting, Feed Table
1
left
67
1120519
Section, Feed Table Frame
1
right
ref
1501760
Serial Number Plate
1
ref
1500598
Whip, Grease
2
13/16 x 52
ref
1500940
Whip, Grease
2
13/16 x 77
ref
1080051
Spacer, Feed Table
2
2-1/4 bronze
ref
1080029
Latch, Feed Table Wing
1
left
ref
1080097
Latch, Feed Table Wing
1
right
ref
1120045
Pin Assembly, Feed Table
2
lock
ref
1080048
Shaft, Feed Table Mounting
2
ref
1540102
Cylinder, Hydraulic
2
ref
1080013
Feed Table Complete
1
8-foot
Item#
Part#
Description
Qty.
Remarks
