Ag-Bag G7000 - Manual (Page 19)

19
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
G7000 June 2004
Appendix A
PTO Tractor - Parts List
Item# Part# Description Qty. Remarks
1 Ref. Ring, Retaining - Quick Disconnect Collar 1
2 Ref. Collar, Quick Disconnect - w/Retaining Ring 1
3 Ref. Pin, Quick Disconnect - w/Spring 1
4 Ref. Yoke, Tractor End - w/Collar & Pin 1
Ref. Ring, Retaining - Bearing 8
6 1501790 U-Joint 2
7 Ref. Pin, Spring - Tractor End 1
8 Ref. Yoke, Outer Tube 1
9 Ref. Tube, Outer 1
10 1501722 Bearing, Shield Outer 1 255080005R02
11 Ref. Shield, Complete 1
12 Ref. Shield, Outer Half - w/Bearing 1
13 Ref. Shield, Inner Half - w/Bearing 1
14 1501723 Bearing, Shield Inner 1 255080006R02
15 Ref. Tube, Inner 1
16 Ref. Pin, Spring - Implement End 1 341045000R10
17 Ref. Yoke, Inner Tube 1
18 Ref. Yoke, Implement End 1
19 Ref. Pin, Taper Lock 1
20 Ref. Pin, Shear - w/pin 1
