Ag-Bag G7000 User Manual
Page 23
23
P
ARTS
M
ANUAL
Ag-Bag International, Ltd.
G7000 June 2004
Appendix A
Planetary Cooling System - Parts List
Item#
Part#
Description
Qty.
Remarks
1
1020011
Shaft, Beater Bar Stub
1
3 x 8-9/16 Drive
2
1100093
Spacer, Pump Coupling - Beater Driven
1
3
1520766
Adaptor, Splined 1.25 14T to 7/8 13T
1
4
ref.
Capscrew, Hex
4
5/8-11nc x 5-1/2
5
ref.
Lubricator
1
6
1020035
Bearing, 4-Bolt Flange Shaved
1
2-3/16
7
1120058
Spacer, Beater Bar Motor Mount
4
8
1020009
Mount, Beater Bar Hydraulic Motor
1
9
ref.
Washer, Flat
4
5/8
10
ref.
Nut, Hex
4
5/8-11nc Lock
11
1541860
Pump, Hydraulic Tyrone 180cc
1
A PAD CW ROT
12
ref.
Coupler, Pump Pressure
1
13
ref.
Coupler, Pump Suction
1
14
ref.
Screen Chaff
1
15
1502039
Cooler, Oil Hayden
1
16
ref.
Coupler, Oil Cooler
2
17
ref.
Hose Assembly, Pressure - Oil Cooler
1
18
ref.
Hose Assembly, Return - Oil Cooler
1
19
ref.
Hose Assembly, Suction - Pump
1
20
ref.
Hose Assembly, Pressure - Planetary
1
21
ref.
Coupler, Planetary Inlet
2
22
ref.
Reducer, Planetary Ports
2
23
ref.
Hose Assembly, Pressure - Pump
1
24
1520693
Planetary, RR3500 26:1
1
25
1501997
Gauge, Sight
1
3/8
26
ref.
Coupler, Planetary Outlet
1
27
ref.
Coupler, Filter Inlet
1
28
1540166
Base, Filter
1
29
1540167
Filter, Hydraulic
1
30
ref.
Coupler, Filter Outlet
1
31
ref.
Hose Assembly, Filter Outlet
1
32
ref.
Coupler, Hardline
4
33
ref.
Hardline Assembly
2
