=9=9,QVWDOODWLRQ+HLJKWV
Upper (Inner) Duct Cover (B) 24.25ļ
Lower (Outer) Duct Cover (A) 18.5ļ
Accessory Lower (Outer) Duct Cover (A) 31.5ļ
Actual *VENTED *RECIRCULATING
Ceiling Installation Installation
Height Height Height
7Ļ 24”to 28” 24”to 28”
8Ļ 0” 24” to 29” 24” to 29”
8Ļ 1” 24” to 30” 24” to 30”
8Ļ 2”
24” to 30” 24” to 30”
8Ļ3” 24” to 30” 24” to 30”
8Ļ 4” 24” to 30” 24” to 30”
8Ļ 5” 24” to 30” 24” to 30”
8Ļ 6” 24” to 30” 24” to 30”
8Ļ 7” 24ļ to 30” 24” to 30”
8Ļ 8” 24” to 30” 24” to 30”
8Ļ 9” 25” to 30” 24” to 30”
8Ļ 10” 26” to 30” 24” to 30”
8Ļ 11” 27” to 30” 24” to 30”
9Ļ 0”
28” to 30” 2” to 30”
9Ļ 1” 29”to30” 25” to 30”
9Ļ 2” 30” 26” to 30”
9Ļ 3” 27” to 30”
9Ļ 4” 28” to 30”
9Ļ 5” 29” to 30”
9Ļ 6”
30”
9Ļ 0ļ 24ļ to 30ļ 24ļ to 28ļ
9Ļ 1ļ 24ļ to 30ļ 24ļ to 29ļ
9Ļ 2ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 3ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 4ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ5ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 6ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 7ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 8ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 9ļ 24ļ to 30ļ 24ļ to 30ļ
9Ļ 10ļ 25ļ to 30ļ 24ļ to 30ļ
9Ļ 11ļ
26ļ to 30ļ 24ļ to 30ļ
10Ļ 0ļ 27ļ to 30ļ 24ļ to 30ļ
10Ļ 1ļ 28ļ to 30ļ 24ļ to 30ļ
10Ļ 2ļ 29ļ to 30ļ 24ļ to 30ļ
10Ļ 3ļ 30ļ 25ļ to 30ļ
10Ļ 4ļ 26ļ to 30ļ
10Ļ 5ļ 27ļ to 30ļ
10Ļ 6ļ 28ļ to 30ļ
10Ļ 7ļ 29ļ to 30ļ
10Ļ 8ļ
30ļ
*Based on 36 ļ countertop height.
Installation Preparation
DETERMINE INSTALLATION HEIGHT
• Telescopic duct covers are provided to conceal
the ductwork running to the ceiling.
• This hood can be installed for vented or
recirculating operation. All necessary parts are
shipped with the hood.
NOTE: Installation height should be measured from
the cooking surface to the bottom of the hood.
The vent hood must be installed 24ļ min. and
30ļ max. above the cooking surface. The hood
installation height, from the cooking surface to the
bottom of the hood, depends upon ceiling height
and duct cover limitations.
24” Min.
30” Max.
36" Min.
DUCT COVER DIMENSIONS
=;6366'XFW&RYHU$FFHVVRU\
This accessory is available for installation with
ceiling heights above 9 feet to 10 feet and higher.
This accessory consists of one 31-1/2ļlower duct
cover.
ACCESSORY ZX90010
SUPPLIED
ZX7510SPSS (
N
ee
d
Ac
ce
ss
or
y
Lo
wer Duct Cover 31.5
ļ
)
8
9-1/4ļ
11-7/8ļ
