• Allow for sufficient heat dispersion when installed on a rack.
• Handle the power cord carefully.
• Hold the plug when unplugging the cord.
• Keep the unit free from moisture, water, and dust.
• Unplug the power cord when not using the unit for long periods of time.
• Do not obstruct the ventilation holes. (For units with ventilation holes.)
• Do not let foreign objects in the unit.
• Do not let insecticides, benzene, and thinner come in contact with the unit.
• Never disassemble or modify the unit in any way.
GENERAL NOTES ON USE
American DJ ® AUDIO • DCD-PRO250™ INSTRUCTIONS MANUAL • PAGE 5
PREPARATIONS
1. Check that the carton contains the following items:
1) Main unit 2) Control unit
3) Operating instructions ( this booklet) 4) Two sets of RCA cables.
5) Two Control cords (6 feet / 1.8 meters)
2. Installing the Units
Mount the units onto your console or rack with 19" EIA rack rails.
CAUTION:
• The player will work normally when the main
unit is mounted with the front panel within
15 degrees of the vertical plane. If the unit is
tilted excessively, discs may not be loaded or
unloaded properly. (Figure 6)
• The control panel's LCDs are designed to be
clearly visible within the angles shown in
Figure 7. Mount the control unit so that the
visual angle is within this range.
Fig. 6
Fig. 7
3. Connections
1) Turn off the POWER switch.
2) Connect the RCA pin cables to the inputs on your mixer.
3) Connect the control cables to the REMOTE connector on the main unit.
CAUTION:
Be sure to use the supplied control cables. Using another type of cable may result in damage.
Be sure the power is off when connecting the control cables. Otherwise the units may not work properly.
