CHECK INSTALLATION HARDWARE

Locate the hardware accessory box packed with the hood and check contents.

Installation Preparation

29-7/8"

11-1/2"

12"

27-3/4"

Mounting bracket

1 charcoal filter for

recirculating installation

2-piece decorative duct

cover (dimension shown

for reference only)

Air deflector for

recirculating

installation only

Duct bracket

14-5/8≤

to top of

bracket

ALIGN BOTT OM EDGE

WITH PENCIL

LINE,

INDICA TING BOTT OM

OF THE HOOD

Drill 2 (two) 3/16≤ pilot holes through studs or rear wall support

REAR WALL

MOUNTING

TEMPLA TE

49-80405 04-06 JR

Wall mount template

HARDWARE PACKAGE

Locate and count

screws

3 wood

screws

3 wall

fasteners

3 wall bracket

screws

12 hood

attachment

screws

27-3/4”

12-7/8”

23-7/8”

11-1/2”

Stainless steel filter

2 thumb

screws
