American Standard 2397.202 IBSTC - Manual (Page 2)

H122
© 2008 AS America Inc.
PRINCETON™ RECESS BATH W/ LUXURY
LEDGE AND INTEGRAL OVERFLOW
AMERICAST ® BRAND ENGINEERED MATERIAL
Revised 2/08
1524mm
(60)
864mm
(34)
FINISHED
WALL
19mm
(3/4)
FINISHED
WALL
229mm x 305mm
(9 x 12) CUTOUT
C/L OF DRAIN
197mm
(7-3/4)
ROUGH
FLOOR
445mm
(17-1/2)
464mm
(18-1/4)
149mm
(5-7/8)
SEE FITTING SPECS
FOR DIMENSION
C/L OF
SPOUT
C/L OF
VALVES
C/L OF
SHOWER ARM
435mm
(17-1/8)
23mm
(15/16)
1651-1981mm
(65-78)
OPTIONAL
1-1/2 N.P.S.M.
THREADS OR
1-1/2 O.D. TUBING
SLIP JOINT
102mm
(4) 305mm
(12)
SEE
NOTE
89mm
(3-1/2)
C/L OF
SUPPLIES
FINISHED
WALL
TILING FLANGE
GENERAL SPECS FOR 2396/2397ICH, IBS BATHING POOL
60 x 34 x 17-1/2 In. (1524 x 864 x 445mm)
127 Lbs. (58 Kg.)
477 Lbs. (217 Kg.)
42 Gal. (159 L)
42 x 19 In. (1067 x 483mm)
56 x 25 In. (1423 x 635mm)
9-1/2 In. (241mm)
34 Lbs./Sq.Ft. (163 Kgs./Sq.m)
8.1
24.1
INSTALLED SIZE
WEIGHT
WEIGHT w/WATER
GAL. TO OVERFLOW
BATHING WELL AT SUMP
BATHING WELL AT RIM
WATER DEPTH TO OVERFLOW
FLOOR LOADING
(PROJECTED AREA)
PTS.
CUBE (FT3)
NOTES:
LEFT HAND OUTLET SHOWN, RIGHT HAND REVERSE DIMENSIONS.
(2396.202.ICH).
DRAIN AND OVERFLOW ESCUTCHEON INCLUDED WITH BATH.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH BATH
FOR DRAIN INSTALLATION
BATH FAUCET NOT INCLUDED AND MUST BE ORDERED SEPARATELY.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH FITTING.
CONCEALED PIPING NOT FURNISHED.
PROVIDE SUITABLE REINFORCEMENT FOR ALL WALL SUPPORTS.
■ REFER TO INSTALLATION INSTRUCTIONS SUPPLIED WITH BATH.
IMPORTANT: Dimensions of fixtures are nominal and may vary within the range
of tolerances established by ANSI Standard A112.19.4 These measurements are
subject to change or cancellation. No responsibility is assumed for use of
superseded or voided leaflet.
STUD
SHIM
DRY WALL
TILE
SEALANT
TUB
ROOFING NAIL
STEEL
STUD
SHIM
DRY WALL
WASHER
TILE
SEALANT
TUB
4" (102mm)
DRYWALL
SCREW
WOOD STUDS STEEL STUDS
Below is shown typical cross sections of the tub
rim showing typical wall constructions.
51 x 102mm (2 x 4) WOOD
STRINGER FULL LENGTH
BARRIER FREE
