hp pavilion fx50 15” lcd monitor
Ad justing Your Moni tor
10 English English
En
glish
Automatic Setup
Using the Auto button and the test pattern on the CD-ROM
provided, you can easily optimize your screen performance.
1 Insert the CD-ROM provided into the PC. Run the program
D:\auto.exe to display a pattern used for setup.
2 Press the Auto button. Normally, this should produce a stable,
centered image.
Your optimizer utility also contains driver for Windows 95,
Windows 98 or Windows 2000 D:\Drivers\P3901.INF.
Manual Setup
Follow these steps only if further adjustments are needed. For further
information, refer to “Using Your Monitor” on page 11.
1 Display the pattern using the CD-ROM as described above.
2 Press
Enter to display the OSD menu.
3 Select the Geometry icon.
4 Select Pixel Clock and adjust the value to minimize
vertical bars.
5 Select Phase and adjust the value to minimize horizontal
bars.
6 Select Horizontal Position and Vertical
Position to adjust screen position.
7 Press the Exit button to save the values.
