ENWW 26 Appendix B Technical Specifications
Preset Video Modes
The monitor automatically recognizes many preset video input modes that will appear properly
sized and centered on the screen.
Entering User Modes
The video controller signal might occasionally call for a mode that is not preset if:
• You are not using a standard graphics adapter.
• You are not using a preset mode.
It this occurs, you have to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The
monitor automatically stores the new setting, then recognizes the new mode just as it does a
preset mode. In addition to the factory preset modes, there are at least ten user modes that can be
entered and stored.
Table B-2: Factory Preset Video Input Modes
Preset Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
1 640 x 480 31.469 59.94
2 720 x 400 31.469 70.087
3 800 x 600 37.879 60.317
4 1024 x 768 48.363 60.004
5 1280 x 720 45.00 60.00
6 1280 x 1024 63.98 60.02
7 1440 x 900 55.94 59.89
8 1600 x 900 60.00 60.00
9 1680 x 1050 65.29 60.00
10 1920 x 1080 67.50 60.00
Table B-3: HDMI High Definition Factory Preset Video Modes
Preset
HD Video Display
Resolution
Resolution
Horizontal Frequency
(kHz) Vertical Frequency
(Hz)
1 480p 720 x 480 31.469 60
2 720p60 1280 x 720 45 60
3 576p 720 x 576 31.25 50
4 720p50 1280 x 720 37.5 50
5 1080p60 1920 x 1080 67.5 60
6 1080p50 1920 x 1080 56.25 50
