HP Passport 1912nm 18.5-inch Internet Monitor - Manual (Page 16)

4. Connect the upstream end of a USB cable to the USB In connector on the monitor's rear panel
and the downstream end to a USB Out connector on the PC.
NOTE: This step is optional. However, the USB cable is required for the USB Out ports and
the 4-in-1 media card reader on the monitor to function in PC mode.
Figure 2-11 Connecting a USB Cable
5. Connect one end of an audio cable to the Audio In connector on the monitor's rear panel and the
other end to an Audio Out connector on the PC.
NOTE: This step is optional. However, the audio cable is required for the monitor's speakers to
function in PC mode.
Figure 2-12 Connecting an Audio Cable
10 Chapter 2 Setting Up the Monitor ENWW
