Left side
Component Description
(1) Power connector Connects an AC adapter.
(2) Battery light ● White: The computer is connected to external power.
If a battery installed, the battery is fully charged.
● Amber: The computer is connected to external power
and the battery is charging.
● Off: The computer is not connected to external power.
● Blinking: The computer is in the Sleep state.
(3) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
(4) Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(5) Hard drive light ● Blinking white: The hard drive is being accessed.
● Amber: HP 3D DriveGuard has temporarily parked the
hard drive.
(6) HDMI port Connects an optional video or audio device, such as a
high-definition television, or any compatible digital or audio
component.
(7) USB 2.0 port Connects an optional USB 2.0 device.
Left side 11
