HP StorageWorks 2.140 Director Switch - Manual (Page 157)

HA-Fabric Manager user guide 155
NOTE: Default zones are only supported in Homogeneous Fabric interop mode. Default zones are
not supported in Open Fabric interop mode. If default zoning is not available, the Default Zone
button is disabled.
To disable the default zone:
1. Display the zone library. See ” Displaying the zone library ” on page 149.
The Zoning dialog box is displayed ( Figure 91 on page 149).
2. Select the fabric for which you want to disable the default zone.
3. Disable the default zone by selecting Default Zone.
4. Click OK.
Exporting a zone set
You can export a zone set as an XML file and import it to a different zone set library on the HAFM
appliance or to a zone set library on another appliance.
NOTE: You can export only one zone set at a time.
To export a zone set:
1. Display the zone library. See ” Displaying the zone library ” on page 149.
The Zoning dialog box is displayed ( Figure 91 on page 149).
2. Select the zone set that you want to export in the Zone Sets list.
3. Click Export.
The Export Zone Set dialog box is displayed (
Figure 96 ).
Figure 96 Export Zone Set dialog box
4. Select the folder in which you want to save the XML file.
5. Enter a name for the file in the File name box.
