HP StorageWorks 2.140 Director Switch - Manual (Page 155)

HA-Fabric Manager user guide 153
The Activate Zone Set dialog box is displayed ( Figure 93 ).
.
Figure 93 Activate Zone Set dialog box
4. Verify the information and click OK.
A confirmation message is displayed (
Figure 94 ).
Figure 94 Activate Zone Set confirmation message
5. Click Yes to continue.
The Zoning dialog box is displayed.
6. Click the Active Zone Set tab to view the active zone set and its zones.
Verify that the switch is being managed properly.
NOTE: Only one appliance should perform discovery at a time; otherwise, logon conflicts can
occur.
7. Click OK.
Deactivating a zone set
To deactivate a zone set:
1. Display the zone library. See ” Displaying the zone library ” on page 149.
The Zoning dialog box is displayed ( Figure 91 on page 149).
2. Click Deactivate.
