C-2 Compaq NC3134 Fast Ethernet Server Adapter User Guide
Upgrade Module Specifications
Environmental and safety specifications for the upgrade modules are the same as those for the
NC3134 Server Adapter, as shown in Table C-1. All other specifications are the same except
where noted.
NC3132 10/100 Upgrade Module
Table C-2
NC3132 10/100 Upgrade Module Specifications
Specification Description
Network Controller Chipset Intel 82558 MAC/PHY
Standards Supported IEEE 802.3x, 802.3u,802.1p, and 802.1Q
Connector and Distances See Table C-8
Dimensions 5.7 x 3.9 inches (L x W), 16.5 cm x 64 cm
Agency Approvals See Table C-1
Power Requirements 800 mA @ 5V max
NC3135 10/100 Upgrade Module
Table C-3
NC3135 10/100 Upgrade Module Specifications
Specification Description
Network Controller Chipset Intel 82559 MAC/PHY
Standards Supported IEEE 802.3x, 802.3u,802.1p, and 802.1Q
Connector and Distances See Table C-8
Dimensions 5.7 x 3.9 inches (L x W) 16.5 cm x 64 cm
Agency Approvals See Table C-1
Power Requirements 375 mA @ 5V max
