Icon Main Menu Submenu Description
Mode Display Displays the resolution, refresh rate and frequency information on
the screen each time the OSD Main Menu is accessed. Select:
● On
● Off
The factory default is Off.
Power-On Status
Display Displays the operating status of the monitor each time the monitor
is powered on. Select the location to display the status to:
● Top
● Middle
● Bottom
● Off
The factory default is Top.
DDC/CI Support Allows the computer to control some OSD menu features such as
brightness, contrast and color temperature. Set to:
● On
● Off
The factory default is On.
Sleep Timer Provides the timer adjustment menu options:
● Set Current Time - sets the current time in hours and minutes
● Set Sleep Time - sets the time you want to place the monitor
in sleep mode
● Set on Time - sets the time you want the monitor to wake up
from sleep mode
● Timer - sets the Sleep Timer feature On or Off. The default
setting is Off
● Sleep Now - immediately sets the monitor to enter sleep
mode
OSD Control Adjusts the position of the OSD menu on the screen.
Horizontal Position Changes the viewing position of the OSD menu to the left or right
area of the screen. The factory default range is 50.
Vertical Position Changes the viewing position of the OSD menu to the top or
bottom area of the screen. The factory default range is 50.
OSD Timeout Sets the time duration in seconds that the OSD is visible after the
last button is pressed. The factory default is 30 seconds.
OSD Transparency Adjust to view the background information through the OSD.
Information Selects and displays important information about the monitor.
Current Settings Provides the current input video mode.
Table 4-2 OSD Menu (continued)
24 Chapter 4 Operating the Monitor
