Page 13: 3setting up the monitor
3
Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Rear Components
Figure 3-1
Rear Components
Component
Function
1
USB Downstream
Connectors
Connects optional USB devices to the monitor.
2
USB Upstream
Connector
Connects the monitor USB hub to a host USB port/hub.
3
DVI-D Connector
Connects the DVI-D signal cable to the monitor.
4
VGA Connector
Connects the VGA signal cable to the monitor.
5
Cable Lock Provisions
Provides slots for use with cable security locks.
6
AC Power Connector
Connects the AC power cord to the monitor.
Rear Components
5
