This Paper applies to the following NAS 8000 configurations:
Date Date
NAS 8000 Configuration | OSCP Testing Completed | Certified Oracle compatible
NAS 8000 w/VA 7100 | May 21, 2002 |
NAS 8000 w/VA 7400 | May 21, 2002 |
storage diagram for VA 7100
Volume Group: VG1
File Vol: Gen_1
Nfs Exports:
/SomeExports
LUN 1
File Vol: Oracle
Nfs Exports:
/Oracle_Archive_Logs
/Oracle_Data
/Oracle_Sys
/Oracle_index
/Oracle_Rollback
/Oracle_Redo
This diagram depicts physical storage as a single
redundancy group – because this is a VA 7100.
One LUN is shown. LUNs aggregate the
storage in a single redundancy group into one or
more general “pools” of storage. Multiple LUNs
could be created.
One volume group is shown. Volume groups
combine one or more LUN storage pools into a
“volume” of storage that can be allocated by the
NAS 8000 operating system for use.
Two file volumes are shown. File volumes partition
the storage volumes into accessible storage (file
systems).
Seven directories/nfs shares are shown. These are
The mount points that various clients can use to
gain access to the NAS 8000 storage.
VA 7100 Array Storage Diagram
