13 Alternative Rack Mounting (4-Post)
Version 2, April 2001
Introduction
This chapter provides the instructions for mounting the HP Netserver in a
four-post (column) HP Systems rack. Figure 13-1 shows the Systems rack. If you
have the newer 4-post HP System/E or System/U racks, go to Chapter 8. If you
are mounting the Netserver in a 2-post non-HP rack, refer to Chapter 7, or see the
documentation in the appropriate rack accessory kit.
a
b
d
e
Characteristics of
HP System Rack:
a. 3-Cornered Columns
b. Fan-Only Vent
c. "HP Systems" Name Plate
d. EIA Units Marked by Triangles
e. Anti-Tip Foot Extends
Out Front Only
c
Figure 13-1. HP System Rack
