Managing the HAFM application 70
You can create views that show only certain fabrics. If you discover or import a SAN with more
than 2000 devices, the devices appear on the Product List, but do not appear on the Physical Map.
Instead, the topology area shows a message stating that the topology cannot be displayed. You
can create a new view to filter the number of devices being discovered.
Creating a customized view
To customize the main window, perform the following procedure:
NOTE: Customized view settings reside on the appliance; all users who log on to the same
appliance are able to select that view.
1. Perform one of the following to open the Create View dialog box:
• Select View > Create View from the HAFM menu bar.
• Click the View tab and select Create View.
The Create View dialog box with the View Members tab opens (
Figure 34 ).
Figure 34 Create View dialog box (View Members tab)
2. Enter information in the following boxes.
• Name
• Description
All fabrics appear on the map.
3. If you want to filter the fabrics that appear on the Physical Map, continue to step 4 ; otherwise
proceed to step 7 .
4. Select the Include Assets via Selection option.
