HA-Fabric Manager user guide 63
5. Stop the HAFM appliance Services by selecting the Start > Programs > HAFM > Stop
Services.
A DOS window displays messages of services being shut down.
6. Increase the default SNMP settings. If the device is running heavy traffic or is known to have
slow SNMP response time, moderately increase the SNMP timeout (default timeout is one
second) and retry count (default count is one retry).
7. These two values are controlled by two VMParameters residing in the
bin\HAFMService.ini
file when the application is running as a Windows service:
smp.snmp.timeout and smp.snmp.retries. For example, specifying
“
-Dsmp.snmp.timeout=5
” and “
-Dsmp.snmp.retries=1
” instructs the server to use five
seconds as the SNMP timeout and one retry as the retry count.
NOTE: The higher the values, the longer discovery will spend waiting for a SNMP response. This
translates into slower system performance.
8. Start HAFM Services by selecting the Start > Programs > HAFM > Start Services.
Configuring IP addresses and community strings
You can alter the database of selected IP addresses, SNMP community strings, Product type, and
Access that the application uses to perform discovery, communication functions, and password
authentication.
Adding an IP address
To add IP addresses and subnets through which the SAN can be discovered, perform the following
procedure:
1. Select Discover > Setup from the HAFM menu bar.
The Discover Setup dialog box opens (
Figure 25 ).
2. Click Add.
The Domain Information dialog box opens (
Figure 28 ).
3. Click the IP Address tab.
Figure 28 Address Properties dialog box (IP Address tab)
4. Enter the appropriate information for the product to be added in the following boxes:
