Optional HAFM features 118
The Port Properties dialog box appears ( Figure 76 ).
Figure 76 Port Properties dialog box
7. Enter a port number in the Port Number box.
8. Select a port type from the Port Type list (available only for multiport devices).
9. Click OK.
10. Optionally, right-click a planned device icon and select Planned Device.
The device changes from a planned device to an implemented device.
Configuring ports
You can configure port numbers and types for planned devices.
NOTE: To configure planned ports, planned devices must be connected.
1. Right-click a planned device icon on the Physical Map and select Ports.
2. Click the small triangle next to the port number.
The Port Properties dialog box appears (
Figure 76 ).
3. Enter a number in the Port Number box.
4. Select a port type from the Port Type list.
5. Click OK.
Planning rules
This section describes how to use planning rules to evaluate a plan.
Planning rules specify criteria for a plan evaluation. Rules are stored in the text file
\Server\Config\Other\rules.dat.
You can open the
rules.dat
file
using any text editor.
Planning rules syntax and format
Planning rules must follow a certain syntax and format. Table 13 describes the planning rule
parameters.
NOTE: You must be an advanced user with administrator privileges to edit planning rules.
