Using the HAFM Window
51 High Availability Fabric Manager User Guide
Use this dialog box to perform the major tasks for configuring zoning on the
fabric:
■ Configure zone sets by combining zone members (attached nodes)
■ Configure zone sets by combining zones
■ Clear zones
■ Delete zones and zone sets
■ Import and export zone sets
■ Display zone properties
■ Copy zones and zone sets
■ Find zone members in zones
■ Find zones in zone sets
■ Display zone sets, zones, and zone members in the library
Refer to “ Using the Zoning Library ” on page 145 for details on zoning and the use
of this dialog box.
Layout Icons
In the Fabrics View, the Layout Icons icon ( Figure 19 ) is available when the
Topology tab is selected. Click the Layout Icons icon to arrange the icons in the
Topology tab view area in the default layout, either circular or spring. To change
the original default layout (circular), choose the Layout Icons icon, and click
Spring.
Spring shortens the length of the ISLs in the Topology tab view area, and springs
the product icons closer together. Circular displays the fabric in a more spread out,
circular layout.
Figure 19: Layout Icons icon
