Fabric Zoning
145 High Availability Fabric Manager User Guide
Configuring Zoning through the HAFM
This section provides procedures for using the menu options available through the
HAFM Fabrics tab to configure and manage zoning. For information on other
menu options, refer to
Chapter 3 .
To configure new zones and a zone set, then activate a new zone set for the fabric,
follow these three steps:
1. Create zones. Follow steps under Configure Zones and Zone Sets on page 148
under “ Configuring Zoning through the HAFM .”
2. Create a zone set. Follow steps in the “ Configure Zones and Zone Sets ”
section on page 148.
3. Activate the zone set. Follow steps under “ Activate Zone Sets ” on page 162.
Note: Designing zoning can be a complex task, especially for multiswitch fabrics. You
should obtain help from HP’s professional services organization before configuring
zoning.
Using the Zoning Library
Open the Zoning Library dialog box in either the Products or Fabrics tab by
choosing Zoning Library from the Configure menu on the menu tab.
Figure 60: Zoning Library dialog box
