B Technical Specifications
The following table contains physical and performance characteristics, user environment and
regulatory information.
Item Description
Physical Characteristics
Color Black
Dimensions Height 7.1”/181 mm
Length 3.9”/100 mm
Width 2.8”/71 mm
Weight (without cable) Approximately 8.7 ounces / 246 g (reader)
Approximately 8.7 ounces / 246 g (base charger)
Electrical Characteristics
Battery Type Li-Ion battery pack
Typical charge time for full charge from full discharge 4 hours with 12V external power supply adapter a
Max 22 hours with Host power (in this case no supply
adapter is needed)
a
Operating Autonomy (continuous reading) 50,000 reads (typical)
Cradle Consumption and DC Input Supply Range Volt 4.75-14 VDC; Power <8W b ; Max 500mA when in host/
bus powered mode b
Performance Characteristics
Light Source LEDs
Roll (Tilt) Angle c Up to ± 180°
Pitch Angle c ± 40°
Skew (Yaw) Angle c ± 40°
Field of View Field of View
a Charge Times are much lower when battery is within daily typical operating condition.
b Typical input current measured under factory default configuration.
c Based on ISO 15423 specifications.
