HP RP7 Retail System Model 7100 - Manual (Page 35)

Decode Capability
1D Bar Codes
2D / Stacked Codes
The scanner is capable of decoding the following symbologies using multiple frames (i.e. Multi-Frame Decoding):
● PDF-417
● QR Code
● Aztec
● Datamatrix
● Inverse Datamatrix
● Datamatrix is configurable for the
following parameters:
◦ Normal or Inverted
◦ Square or Rectangular Style
◦ Data length (1 - 3600
characters)
● Maxicode
● QR Codes (QR, Micro QR and
Multiple QR Codes)
● Aztec
● Sweden Post
● Portugal Post
● LaPoste A/R 39
● 4-State Canada
● Postal Codes
● Australian Post
● Japanese Post
● KIX Post
● Planet Code
● Postnet
● Royal Mail Code (RM45CC)
● Intelligent Mail Barcode (IMB)
● PDF-417
● MacroPDF
● Micro PDF417
● GS1 Composites (1 - 12)
● Codablock F
● French CIP13 a
● GS1 DataBar Stacked
● GS1 DataBar Stacked
Omnidirectional
● GS1 DataBar Expanded Stacked
● GSI Databar Composites
● Chinese Sensible Code
● Inverted 2D codes
a It is acceptable to handle this with ULE.
Interfaces Supported USB Com Std., USB Keyboard, USB (see Selecting the Interface Type
on page 19 for a listing of available interface options)
User Environment
Operating Temperature 32° to 122° F (0° to 50° C)
Storage Temperature -4° to 158° F (-20° to 70° C)
Humidity Operating: 5% to 90% relative humidity, non-condensing
Drop Specifications Scanner withstands 18 drops from 1.8 meters (5.9 feet) to
concrete
Ambient Light Immunity Up to 100,000 Lux
Contaminants Spray/rain Dust/particulates IEC 529-IP52 (scanner only)
ESD Level 16 KV
Regulatory
Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated
June 24, 2007.
Radio Features
Frequency Range 2400 to 2483.5 MHz
Range (in open air) 30 m
29
