Depth of Field (Typical)
Symbology
SR:
Code 39
5mil: 1.6” - 7.5” (4.0 - 19cm);
10mil: 0.4” - 11.8” (1.0 - 30cm);
20mil: up to 17.7” (up to 45cm)
EAN
7.5mil: 0.5” - 10.6” (2.0 - 27cm)
13mil: 0.6” - 15.7” (1.5 - 40cm)
PDF-417
6.6mil: 1.0” - 5.9” (2.5 - 15cm);
10mil: 0.2” - 8.6” (0.5 - 22cm);
15mil: 0.6” - 13.4” (1.5 - 34cm)
DataMatrix
10mil: 0.8” to 6.3” (2.0 - 16cm)
15mil: 0” to 9.3” (0 - 23.6cm)
QR Code
10mil: 1.2” to 4.9” (3 - 12.5cm)
15mil: 0” to 7.5” (1 - 19.0cm)
Minimum Element Width
Standard Range:
1D Min. Resolution = 4 mil
PDF-417 Min.Resolution = 5 mil
Datamatrix Min. Resolution = 7 mil
Print Contrast Minimum
25% minimum reflectance
1
13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environmental light, 20° C, label
inclination 10°.
Decode Capability
1D Bar Codes
●
UPC/EAN/JAN (A, E, 13, 8)
●
UPC/EAN/JAN (including P2 /P5)
●
UPC/EAN/JAN (including; ISBN /
Bookland & ISSN)
●
UPC/EAN Coupons
●
Code 39 (including full ASCII)
●
Code 39 Trioptic
●
Code39 CIP (French
Pharmaceutical)
●
LOGMARS (Code 39 w/ standard
check digit enabled)
●
Danish PPT
●
Code 32 (Italian Pharmacode 39)
●
Code 128
●
Code 128 ISBT
●
Interleaved 2 of 5
●
Standard 2 of 5
●
Interleaved 2 of 5 CIP (HR)
●
Industrial 2 of 5
●
Discrete 2 of 5
●
Datalogic 2 of 5 (China Post Code/
Chinese 2 of 5)
●
IATA 2 of 5 Air cargo code
●
Code 11
●
Codabar
●
Codabar (NW7)
●
ABC Codabar
●
Code 93
●
MSI
●
PZN
●
Plessey
●
Anker Plessey
●
Follet 2 of 5
●
GS1 DataBar Omnidirectional
●
GS1 DataBar Limited
●
GS1 DataBar Expanded
●
GS1 DataBar Truncated
●
DATABAR Expanded Coupon
