Setting Up the Application
71 HA-Fabric Manager User Guide
Adding an IP Address
You can add IP addresses and subnets through which the SAN can be discovered.
Perform the following to add an IP address:
1. Choose Discover > Setup. The Discover Setup dialog box displays, as shown
in Figure 25 on page 70.
2. Click Add. The Domain Information dialog box displays, as shown in
Figure 26 .
Figure 26: Domain Information dialog box (IP Address tab)
3. Enter a description for the product in Description field.
4. Enter the IP address in the IP Address field.
5. Enter the subnet mask associated with the IP address in the Subnet Mask
field.
6. If you want to generate a sequence of IP addresses, perform the following:
■ Choose the Generate a sequence of IP addresses check box.
■ Enter the last IP address in the Last IP field.
Note: All IP addresses in a sequence must be on the same subnet and have the same
first three octets.
7. Click OK.
