HP StorageWorks 2.32 Edge Switch - Manual (Page 201)

Configuring Zoning
201 HA-Fabric Manager User Guide
Exporting a Zone Set
You can export zone sets as an XML file and then import them into another
appliance’s zone set library, or to a different zone set library on the current
appliance.
Note: You can only export one zone set at a time.
To export a zone set:
1. Choose Configure > Zoning. The Zoning dialog box displays, as shown in
Figure 101 on page 192.
2. Choose a fabric from the Fabric drop-down list. This sets the fabric to target
all zoning actions.
3. Click the Zone Library tab.
4. Choose a zone set in the Zone Sets list.
5. Click Export. The Export Zone Set dialog box displays, as shown in
Figure 106 .
Figure 106: Export Zone Set dialog box
6. If you want to save the document in a different folder, locate and open the
folder.
7. Enter a name for the file in the File name field.
8. Click Export Zone Set. The file is saved to the location you specified.
9. Click OK.
