Optional Features
176
Opening an Existing Plan
1. Choose SAN > Open Plan (or CTRL+O). The Open Plan dialog box
displays, as shown in
.
Figure 95: Open Plan dialog box
2. Choose a plan from the Open Plan drop-down list.
3. Click OK.
Designing a Plan
By designing a plan, you can configure, connect, and arrange planned devices
before implementing the design. This enables you to envision and evaluate the
plan.
Adding Planned Devices
You can either add devices one at a time or add multiple devices at the same time.
Adding Individual Devices
1. Click a device button on the Devices toolbox in the planning window.
2. Click on the Physical Map. The new planned device icon displays on the
Physical Map.
3. Arrange planned icons as necessary.
Adding Multiple Devices
1. Click the Devices button on the Devices toolbox in the planning window. The
Insert Multiple Devices dialog box displays, as shown in
