Optional Features
138 HA-Fabric Manager User Guide
13. Choose an action from the Actions list at the bottom left of the dialog box.
For help with adding specific actions, see “ Event Management Component
Overview ” on page 128.
14. Enter the required information in the Value column for each listed parameter.
15. Click Add. The action you configured displays in the Actions area in the top
half of the dialog box.
16. Repeat step 14 through step 15 to add more actions.
17. Use the buttons to the right of the Actions area to move the action phrases up
or down.
— Click Delete to remove selected rows from the table.
— Click the up and down arrows to move selected actions up and down to
change the order in which the actions are started.
18. Click OK.
Specifying a Rule’s Actions
After specifying a rule’s triggers, you can add actions that the application
performs when trigger conditions are met.
Specifying an E-mail Action
You can configure the application to send an e-mail message when the specified
trigger is fired.
Note: Before specifying an action, you should specify the rule’s triggers. See “ About
Triggers ” on page 128 for instructions.
1. Click the Event Management tab on the main window. The Event
Management tab displays, as shown in Figure 69 on page 133.
2. Click New. The Add Rule dialog box displays, as shown in Figure 70 on
page 134.
3. Choose E-mail from the Actions list at the bottom left side of the dialog box.
The E-mail information displays, as shown in Figure 73 .
