HP StorageWorks 2.32 Edge Switch - Manual (Page 112)

Configuring SAN Products and Fabrics
112 HA-Fabric Manager User Guide
5. Click OK.
Adding Trap Recipients
1. Choose Monitor > Trap Forwarding. The Configure Trap Forwarding
dialog box displays, as shown in Figure 58 .
2. Click Add. The Add Trap Recipient dialog box displays, as shown in
Figure 59 .
Figure 59: Add Trap Recipient dialog box
3. Enter a description of the trap recipient in the Description field.
4. Enter the trap recipient’s IP address in the IP Address field.
5. Enter the trap recipient’s TCP/IP port number in the Port field.
6. Click OK.
7. Click OK.
Removing Trap Recipients
1. Choose Monitor > Trap Forwarding. The Configure Trap Forwarding
dialog box displays, as shown in Figure 58 .
2. Highlight the recipient you want to remove in the Available Recipients table.
3. Click Remove.
4. Click OK.
