Configuring SAN Products and Fabrics
101
Hiding Routes Between Two End-Products
Note:
This feature is only available for fabrics consisting solely of HP M-series
products.
You can use the Hide Route feature to hide routes that Fibre Channel frames must
take between two end-products in a multiswitch fabric. You must show routes
before you can hide routes. See “
Showing Routes Between Two End-Products
on page 99 for instructions on showing routes.
To hide the route, perform the following:
1. Right-click the route (line between end-nodes) or the fabric that includes the
route you want to hide and choose Hide Route.
Viewing Properties of Routes Between Two End-Products
To view the properties of a route, perform the following:
1. Right-click the route and choose Properties. The Route Properties dialog box
displays, as shown in
.
Figure 46: Route Properties dialog box
