HP p1130 21 inch CRT Monitor - Manual (Page 33)

HP 21” Color Monitor User’s Guide
Technical Specifications
32 English English
Technical Specifications
PICTURE TUBE
Size 21-inch,
19.8-inch viewable image
Aperture Grill Pitch 0.24 mm (0, 24 mm)
Face Plate wide anti-reflective
anti static-coating
INTERFACE Detachable Video Cable with 15-pin mini D-SUB Connector
SCANNING FREQUENCY
Horizontal 30 to 130 kHz
Vertical 50 to 170 Hz
MAX. RESOLUTION 2048 x 1536 (75 Hz)
RECOMMENDED
RESOLUTION:
From 1280 x 1024 (85 Hz) to 1920 x 1440 (85 Hz)
WARM-UP TIME 30 minutes to reach optimum performance level
Max PIXEL CLOCK <370 MHz
IMAGE SIZE
Standard: 388 (W)
×
291 (H) mm or 15.2 (W) x 11.4 (H) in
Max: 404 (W)
×
302 (H) mm or 15.9 (W) x 11.9 (H) in
POWER MANAGEMENT
On 135W (max) Constant green LED
Active Off 3W (max) Constant Amber LED
Power Off 0W LED is Off
POWER SOURCE AC 90 to 264 V, 50/60 Hz (max current) 2A
OPERATING
ENVIRONMENT
Temperature
10
°
C to 40
°
C
Humidity 10% RH through 80% RH (without
condensation)
STORAGE ENVIRONMENT
Temperature 0
°
C to 60
°
C
Humidity 5% RH through 90% RH (without
condensation)
SHIPPING ENVIRONMENT Temperature: - 40
°
to +60
°
with PACKAGING
Humidity 5% RH through 95%
°
RH (without
condensation)
CABINET DIMENSIONS 502 (H) 497 (W) 490 (D) mm or 19.7 (H) x 19.6 (W) x 19.3 (D) in
WEIGHT 30.5 kg (30, 5 kg) or 67.2 lbs (67, 2 lbs)
TILT/SWIVEL STAND
Tilt Angle - 5
°
to 15
°
Swivel Angle - 90
°
to 90
°
P4819A_us.fm Page 32 Friday, September 21, 2001 4:00 AM
