Installing and Configuring the Tape Drive for the
NonStop S-Series Server

M8505 Tabletop Tape Drive Installation and User’s Guide— 541949-002

3 -6

Installation

5. Connect the other end of the fiber-optic cable to a Fibre Channel port on a Fibre

Channel ServerNet adapter (FCSA) at the rear of the IOAM enclosure. See

Figure 3-5

for the location of the ports.

Figure 3-5. View of Two FCSAs at Rear of Server

Fiber-Optic Cables
