HA-Fabric Manager user guide 89
NOTE: The Product Type and Access tab may not be available in all situations.
1. Select Discover > Setup.
The Discover Setup dialog box is displayed (
Figure 39 on page 82).
2. Click Add.
The Address Properties dialog box is displayed (
Figure 42 on page 86).
3. Click the Product Type and Access tab. The Product Type and Access tab is displayed
( Figure 44 ).
Figure 44 Address Properties dialog box (Product Type and Access tab)
4. Select the type of device from the Product Type list.
• If you select from the Product Type list, go to step 7.
• If you select Switch from the Product Type list, go to step 5.
• If you select Intrepid 10K from the Product Type list, go to step 5.
5. Enter a user ID in the User ID field.
6. Enter the password in the Password and Retype Password boxes.
7. Click OK.
Turning discovery on and off
To turn discovery on or off, select Discover > On or Discover > Off.
Determining the operational status
NOTE: The Product List panel can be hidden by default. To view the Product List, select View >
Product List or press F9.
