1 HAFM overview
HAFM is a graphical user interface (GUI) that enables you to manage users and products, monitor
products, and open Element Managers.
This chapter describes the following topics:
• HAFM components , page 21
• SAN life cycle , page 24
• Searching the online help , page 25
• System requirements , page 26
HAFM components
The HAFM application is installed on the 1U rack-mount appliance (HAFM appliance) to provide
local access to managed products. HAFM client applications can also be installed on remote user
workstations to provide remote access to the managed products through the HAFM appliance.
Figure 1 shows an example of an HAFM configuration.
Figure 1 Product management options
HAFM Server
10/100 Mbps
Ethernet Hub
Customer Intranet
(10/100 Mbps)
Customer Intranet
(10/100 Mbps)
Remote
Workstation
Remote
Workstation
Director 2/64
Director 2/64
® 3 com
1 2 3 4 6 7 8 9 10 11 12 22 23 24 21 20 19 18 17 16 15 14 13
Power 100M Collision Port Status Green - 100M,Ye llow - 10M, Flash - Activity
MID Baseline 10/100 Hub
3C16411 SuperStack 3 ®
21 20
9 12
24
8 5
17
4
16
1
13
MDIX
10M 5 ENTER
L1 L2 FAN HDD
