HA-Fabric Manager user guide 157
7 Zoning
Zoning defines the communication paths in a fabric. A zone consists of initiator and target ports in
the SAN. Ports can communicate only with other ports in their zone. However, ports can be
members of more than one zone. To zone devices in a fabric, the fabric’s principal switch must be
an HP switch and HAFM must discover and manage it.
HAFM performs zoning discovery once at startup, and thereafter once every two hours during
routine discovery. For best results, HP recommends that you perform zoning five discovery cycles
after starting the HAFM appliance.
The following zoning features are described:
• Zoning limits , page 157
• Zoning naming conventions , page 158
• Zoning configuration , page 158
• Zoning administration , page 166
Zoning limits
You can configure large zone sets with HAFM. Table 23 lists the zoning limits for the edge switches
and directors.
NOTE: Hard zoning is enforced when the firmware initializes. Devices not conforming to zoning
rules are restricted to their assigned zones.
Table 23 Zoning parameter limits
Zoning parameter Maximum value
Number of zone members in a zone 2048
Number of zones in a zone set 1024
Number of unique zone members in a
zone set
2048
Total number of zone members in a
zone set (where a zone member can be
in multiple zones)
4096
Characters per zoning name 64
Number of unique zone members in
HAFM zoning library
2048
