After the programs are installed, VOE starts automatically and will always run as a background process

unless the user deliberately stops it. The installation process installs a VOE icon on the desktop. In

addition, the user will see two new icons in the system tray as shown in the following figure:

Figure 2-1

VOE and ViewSpan Icons

1

VOE icon

Right-click this icon to open the VOE dialog or Quit to stop VOE

2

ViewSpan icon

Right-click icon to bring up Windows display settings dialog or Exit to stop the driver

VOE is set up to automatically start any time the player/computer is booted. To change this default

setting, right-click on the VOE icon and click on the check mark next to Run this application when

PC starts up. When this option is chosen, the user must double-click on the VOE desktop icon to start

the VOE application and user interface each time the player/computer is booted. It is recommended to

keep the default setting so players and displays will automatically associate and connect when the

player/computer is booted.

Figure 2-2

VOE Setting Options

Making Displays Visible to the Software

In order for VOE software to find the displays the user wants to drive, they need to have IP addresses

on the user's network. Refer to the display documentation for details on IP addresses. In order to

distinguish one display from another, each needs a name and location. These can be any text

meaningful to the user. Enter names and locations at the display, using its on-screen menu (refer to the

documentation included with the display), or enter them through VOE when signing on as an

administrator (see

Display Settings on page 28

in this guide for details).

4

Chapter 2 System Setup
