3 IP Address The IP address assigned to the display in the network
4 MAC ID The MAC ID of the display
5 Display Location Will show the Display Location field of the display if it has been created in
the display's OSD menu or with the VOE Display Settings Dialog
6 Display Model Displays the model number of the networked display
7 Player Name Displays the Player Name of the player associated with the display
8 Status Displays the status of the display. Ready to Connect (the display is
available to be associated) or Connected (the display is already
associated with a player and is not available to be associated with any
other player)
VOE Main Menu
Opening a VOE window shows all the displays detected on the network, each on its own line. Columns
on the VOE Main Menu show display information. See Figure 3-1 VOE Main Menu on page 5 .
A display must be highlighted before the user can perform any operations such as changing its name
or location. Highlight a display by clicking any column entry for the display wanted.
Modes and Privileges
The upper left corner of the VOE menu window indicates the mode and privileges of the operator. VOE
opens the user interface in User Mode with no designation in the upper left corner as shown in Figure
3-1 VOE Main Menu on page 5 . However, If the user logs on as an Administrator, the upper left corner
will indicate Master Administrator if the Master Administrator password has been used, or
Administrator if the user entered one of the other three possible administrator passwords. To view these
designations, refer to Figure 3-2 VOE Menu Window - Master Administrator, Administrator, User
on page 6 . For more password information, see Password on page 23 .
Figure 3-2 VOE Menu Window - Master Administrator, Administrator, User
6 Chapter 3 Operating VOE
