USER MANUAL
33014817(2)2006-06 A 23
L1: Left front turn signal
L2: Left rear turn signal
L3: Right front turn signal
L4: Right rear turn signal
L5: Left brake light
L6: Right brake light
L7: Left front running light
L8: Left rear running light
L9: Right front running light
L10: Right rear running light
L11: Left low beam
L12: Right low beam
L13: Left high beam
L14: Right high beam
M: Brake light micro-switch
M1: Starter
M2: Blower
motor
M3: Filter shaker motor
P1: Filter shaker push-button
R1: Open skirt warning light relay
R2: Revolution safety relay
R3: Reverse gear buzzer relay
R4: Fire alarm buzzer relay
S1: Glow plug warning light
S2: Battery warning light
S3: Oil warning light
S4: Water warning light
S5: Parking brake warning light
S6: Clogged air cleaner warning light
S7: Low diesel warning light
S8: Turn signal indicator light
S9: Running light indicator light
S10: High beam indicator light
S11: Open skirt warning light
SE: Skirt
sensor
K: Glow plugs
Wiring diagram SR 1800C B
(See Fig. AJ)
A: 48 V-12 V 40 A power supply
AV: Horn
B:
48 V-600 A battery
CO: Hour counter
C1: Ignition switch
C2: Seat safety micro-switch
C3: Parking brake micro-switch
C5: Blower bulb
C6: Brake light micro-switch
C7: Combination switch
C8: Hazard warning light switch
CR1: Starter electromagnetic switch contact
D1: 6A60
diode
D2: 1N4007 diode
D3: 1N4007 diode
EV: Blower
F:
250 A fuse
F1: Turn signal-hazard warning light fuse:
F2: Horn fuse
F3: Brake light fuse
F4: Running light fuse
F5: Low beam fuse
F6: High beam fuse
F7: Power supply pick-up fuse
F8: 48 V set-up fuse
F9: Meter power supply fuse
F10: Free
F11: Ignition key in indicator light fuse
F12: Accessory relay set-up fuse
F13: Filter
shaker fuse
F14: Start circuit safety fuse
F15: Motor overtemperature warning light relay fuse
F16: Parking brake micro-switch-bimetallic thermostat fuse
F17: Free
F18: Blower
fuse
I: Flashing device
L1: Left brake light
L2: Right brake light
L3: Left front running light
L4: Left rear running light
L5: Right front running light
L6: Right rear running light
L7: Left low beam
L8: Right low beam
L9: Left high beam
L10: Right high beam
L11: Left front turn signal
L12: Left rear turn signal
L13: Right front turn signal
L14: Right rear turn signal
MS: Filter
shaker motor
MT: Service motor
P1: Filter shaker push-button
R1: Start electromagnetic switch coil
R2: Revolution safety relay
S1: Ignition key in indicator light
S2: Parking brake warning light
S3: Running light indicator light
S4: High beam indicator light
S5: Turn signal indicator light
S6: Hazard warning light
S7: Motor overtemperature warning light
S8: Worn broom warning light
SC: Battery charge indicator light
SP: Battery socket-plug
T: Motor overtemperature transducer
